CNC HVR – HYDRAULIC VARIABLE RAKE GUILLOTINE SHEARS
Automatic Solutions, Perfect Cuts...
When you enter length, thickness and type of the metal sheet to be cut into easily programmable controller; blade gap, cutting angle and cutting length are automatically and instantly adjusted. This provides flexibility for various production requests, and prevents time losses completely by aiming high efficiency.
By selecting CNC HVR model developed by ERMAKSAN engineers; you will bring up to date technology to your company with maximum safety, high accuracy and unique ease of handling.
ANTI-TWIST SYSTEM
Anti-twist system keeps the material being cut stable during top blade moves, and prevents twisting while cutting thin and strip-shaped sheet metals.
1000MM ERMAKSAN MOTORIZED BACKGAUGE
With an accuracy of 0.1 mm, the 1 meter long fast backgauge provides precise cutting results. With the automatic folding function for your sheets longer than 1 m, it allows you to freely operate.
LEUZE MLD 520
Prevents undesired accidents by creating an invisible light barrier behind the machine.
FOOT PEDAL SUITABLE FOR SINGLE AND MASS CUTTING
This movable pedal allows to start and finish cutting operation easily anywhere in the cutting area, and to easily stop the operation when desired.
STAINLESS BLADE
Extends the dulling time of the blade while providing a more precise cut for a longer period of time in stainless and black sheet cutting.
SIEMENS ELECTRICAL SYSTEM
Electrical equipment such as the components that make up the motor power circuit, contactor, motor protection, and main switch are offered with proven Siemens quality.
1000 MM FRONT T-SQUARE
It is your best assistant that facilitates the continuous 90° cutting of the sheets.
ANGLE ADJUSTED T-SQUARE
Allows high precision, easy cutting in angled cutting thanks to angle adjusted T-square.
HAWE HYDRAULIC SYSTEM
This system ensures that sufficient amount of oil required for the main rollers, pressing rollers, and feeler adjustment rollers circulates in the system at an accurate pressure.
CUTTING LINE ILLUMINATION SHADE WIRE
Generates projection over sheet metal to be cut to provide high quality and precise cutting.
1000 SIDE T-SQUARE AND FRONT SUPPORT ARMS
While the front arm with t-square allows you to slide the sheet metal 90 degrees (perpendicular) to the machine, the support arms make it easier to work and slide sheet metals, allowing you to make more precise and faster cuts.
FRONT VISOR
Complying with international safety standards, the finger protection provides a safer working environment.
Read more
LASER LIGHT FINGER PROTECTION
Allows the cutting area to be observed better and more easily, allowing the operator to intervene the sheet metal to be cut more easily.
LEVER TYPE PNEUMATIC SHEET METAL SUPPORT SYSTEM
Sheet metal being cut can be slid with minimum scratch thanks to rollers and balls on lever type pneumatic sheet metal support system.
SOLID SHEET METAL SUPPORT SYSTEM
Solid table-type pneumatic sheet metal support system prevents sagging of wide and thin sheet metal to enable more precise cutting
X-TYPE PNEUMATIC SHEET METAL SUPPORT SYSTEM + RTS
More precise cuts are achieved with pneumatic X type levers which prevent sagging of wide and thin sheet metals.
Read more Play
FRONT SHEET METAL SLIDING GROUP WITH BALLS
Front sheet metal sliding system with balls enables faster cutting by simplifying operation and sheet metal sliding
MOTORIZED SHEET METAL SLIDING SYSTEM
After the sheet metal to be cut with shear is placed for the cutting process, cutting process takes place after an automatic system slides the sheet metal, instead of an operator.
WITH T GROOVE AND RULER
T-grooved worktable with static and dynamic rigidity ensures precise cuts and ease of use.
AUTOMATIC FEELER ADJUSTMENT SYSTEM
The automatic feeler adjustment system, which does not require separate adjustments for sheet metals with different thickness, adjusts the gaps between the blades.
OIL HEATING AND COOLING SYSTEM
In the environments where the operating temperature is inconvenient, hydraulic oil is heated up to the desired temperature and it is ensured that the shear operates in the optimum environment.
CENTRAL LUBRICATING SYSTEM
Automatic lubrication of the parts that require lubrication for extended lifetime of the machine by central lubrication system, without the need for an operator.
Read more
LED FITTED BODY
The led fitted body adds aesthetics to the machine, and allows operator to perform cutting operations using the light of machine, without any need to workshop lights.
7” CONTROLLER
With its intuitive interface, 7” touch screen controller developed by Ermaksan with its advanced engineering and sector experience is the closest friend of the operator.
CENTRAL LUBRICATION
Automatic lubrication of the parts that require lubrication for extended lifetime of the machine by central lubrication system, without the need for an operator.
RTS (Return To Sender)
This is the system to remove cut sheet metal automatically from the front part of the machine for performing several operations on the same sheet metal in a minimum time.
ANTI TWIST SYSTEM
Anti-twist system keeps the material being cut stable during top blade moves, and prevents twisting while cutting thin and strip-shaped sheet metals.
PNEUMATIC SHEET METAL SUPPORT SYSTEM (X Type)
Pneumatic X-type arms, which prevent wide and thin sheets from sagging, work parallel to the ground from the bottom, and support the cut sheet during the cutting operation. Thus, more precise cuts are obtained.
