CNC HGS
CNC HGS - HYDRAULIC SWING BEAM SHEARS
High Performance Economic Solutions...
It is a high-performance and economic machine with its modern design, strong steel welded construction body and excellent cutting quality.
Top cutting beam has maximum durability. Quick and precise blade gap adjustment system is located on the right side of the machine. Blade gap adjustment required for high quality cutting can be performed non-gradually from a single side.
HGS series shear, and with its speed, performance and cutting quality: the best choice.
1000MM ERMAKSAN MOTORIZED BACKGAUGE
With an accuracy of 0.1 mm, the 1 meter long fast backgauge provides precise cutting results. With the automatic folding function for your sheets longer than 1 m, it allows you to freely operate.
LEUZE MLD 520
Prevents undesired accidents by creating an invisible light barrier behind the machine.
FOOT PEDAL SUITABLE FOR SINGLE AND MASS CUTTING
This movable pedal allows to start and finish cutting operation easily anywhere in the cutting area, and to easily stop the operation when desired.
STAINLESS BLADE
Extends the dulling time of the blade while providing a more precise cut for a longer period of time in stainless and black sheet cutting.
SIEMENS ELECTRICAL SYSTEM
Electrical equipment such as the components that make up the motor power circuit, contactor, motor protection, and main switch are offered with proven Siemens quality.
1000 MM FRONT T-SQUARE
It is your best assistant that facilitates the continuous 90° cutting of the sheets.
ANGLE ADJUSTED T-SQUARE
Allows high precision, easy cutting in angled cutting thanks to angle adjusted T-square.
CUTTING LINE ILLUMINATION SHADE WIRE
Generates projection over sheet metal to be cut to provide high quality and precise cutting.
FRONT VISOR
Complying with international safety standards, the finger protection provides a safer working environment.
Read more
LASER LIGHT FINGER PROTECTION
Allows the cutting area to be observed better and more easily, allowing the operator to intervene the sheet metal to be cut more easily.
LEVER TYPE PNEUMATIC SHEET METAL SUPPORT SYSTEM
Sheet metal being cut can be slid with minimum scratch thanks to rollers and balls on lever type pneumatic sheet metal support system.
SOLID SHEET METAL SUPPORT SYSTEM
Solid table-type pneumatic sheet metal support system prevents sagging of wide and thin sheet metal to enable more precise cutting
FRONT SHEET METAL SLIDING GROUP WITH BALLS
Front sheet metal sliding system with balls enables faster cutting by simplifying operation and sheet metal sliding
WITH T GROOVE AND RULER
T-grooved worktable with static and dynamic rigidity ensures precise cuts and ease of use.
MANUAL FEELER ADJUSTMENT SYSTEM
Easily adjustable blade feeler system ensures high operation performance and perfect cutting results.
AUTOMATIC FEELER ADJUSTMENT SYSTEM
The automatic feeler adjustment system, which does not require separate adjustments for sheet metals with different thickness, adjusts the gaps between the blades.
OIL HEATING AND COOLING SYSTEM
In the environments where the operating temperature is inconvenient, hydraulic oil is heated up to the desired temperature and it is ensured that the shear operates in the optimum environment.
BACKGAUGE SYSTEM
Simplifies precise cutting by enabling backgauge at different strokes.
FRONT SUPPORT ARM WITH T-SQUARE
Thanks to the stop discs on the t-square arm, it is ensured that the sheet to be cut is parallel to the blades. You can take measurements with the ruler on the arm, and cut continuously with the folded stop latch.
FRONT SHEET METAL SLIDING WITH BALLS
Thanks to the balls on the table, the sheet can be moved easily.
BACK PROTECTION
There are two opposing photocells for back protection conforming to CE standards.
QUIET PUMP
Has a quiet and durable pump enabling operation at high pressures.
LASER CUTTING LINE
Bevel and striped cuts can be made easily in a controllable manner.
