EVO-III
EVO III HYBRID PRESS BRAKE
Next Generation Technology
While manufacturers turn to machines with low energy consumption in order to lower their operating profits, they also shape their production with social responsibility awareness such as environmental awareness and effective use of energy resources. In order to meet these expectations of our customers, we have combined our press brake production experience of more than 30 years with today’s most advanced technologies, and we have offered the next generation EVO III series hybrid press brakes to the benefit of the sector.
The EVO III series, which has a length of 4.1 meters and a capacity of up to 260 tons, offers its users the opportunity to perform difficult bends under high stroke. 6-axis and motorized crowning system features are offered as standard to enable you to obtain more precise bending.
Our solutions with less energy consumption, which were developed with our environmentally friendly perspective, help our customers gain competitive advantage by reducing their total operating costs.
NEW LOOK, SAME TECHNOLOGY!
We are pleased to present our hydraulic press brakes with a more elegant, dynamic and modern look. The improved cabin design is offered as an option upon customer request.
With its cambered and structured body and strong curves, the new design also inspires with its unique colours. With a strong appearance, the updated design has been stylishly reproduced without compromising from the quality of the previous design. It is made of high-strength solid st44 quality steel and has a rigid structure that has been relieved of tension with the latest technology. Thus, a longer life is ensured. While the appearance of this new cabin design changes, the only thing that does not change is the basic values that Ermaksan reflects on every product it produces: innovation, reliability, proactive approach, and customer focus. .
DATA-M LASER PROTRACTOR
Developed by Data M Engineering, it is a powerful solution for measuring bending angles in press brakes.
Read more Play
IRIS PLUS LASER PROTRACTOR
Automatic angle measurement and automatic correction of bending angle
Read more Play
KEBA DIGITAL ANGLE GAUGE
With KEBA angle measuring systems, complex bends can be performed extremely easily and with maximum accuracy.
Read more
MITUTOYO UNIVERSAL ANGLE GAUGE
Can make your measurements more accurately with its sensitive adjustment.
Read more
BARCODE READER
Facilitates the operator's intensive and complex work processes and prevents errors.
Read more
LED BAR GUIDING SYSTEM
Shows the location of the bent pieces and bending stations with coloured LED bars.
Play
START-STOP
This is the optional system that stops the main motor when there is no upper beam movement in the machine within 2 minutes.
START-STOP + SOFT STARTER
This is the STAR - TRIANGLE motor speed change that we use as an option. Ensures safer and easier speed change for the motor.
WILA SMART TOOL LOCATOR
This system determines the order of use of the partial dies, which are mounted on the upper beam in full length, and attached to the top tool holder, by means of laser beam.
4-AXIS BACKGAUGE
Backgauge with 4-axis (X, R, Z1, Z2) servo motor allows you to obtain precise bending of the backgauge with 0.05 mm positioning accuracy according to the desired geometry.
5-AXIS BACKGAUGE
Backgauge with 5-axis (X, R, Z1, Z2, X5) servo motor allows you to obtain precise bending of the backgauge with 0.05 mm positioning accuracy according to the desired geometry.
Read more Play
6-AXIS BACKGAUGE ATF TYPE
ATF type backgauge system with 6-axis servo motor is automatically positioned for optimum bending results.
Read more Play
PNEUMATIC REAR SUPPORTS
This is the latch group that is additionally mounted for easy bending in the machine and can also operate pneumatically apart from the backgauge.
X5 BACKGAUGE FINGER GROUP
X5 servo motorised back gauge tongue desired positioning accuracy of 0.05 mm according to geometry.
Read more
LEUZE MLC510 BACK PROTECTION
The back protection light barrier stops the machine in case an object enters the rear of the machine during operation and ensures safety.
MOTORIZED SHUTTER DOOR REAR COVER
A rear safety door that can be used with motors and manually, and has aluminium partitions, which are provided in anthracite grey and metallic grey colours.
Play
SLIDING TYPE REAR GUARD
With its cover that can be moved manually in a horizontal direc-tion, It is a rear security protection door that can be optionally in-stalled according to customer request, in both body color and or-ange color.
MOTORISED CROWNING SYSTEM
The ideal deflection balance can be achieved with the manual crown-ing system that operates by manually turning the hand wheel.
Read more Play
LASER BEND LINE - B-LIGHT 02
This is a system utilized for bending without the use of backgauge with the help of laser beam, and that allows the bending axis to be clearly visible.
Read more
LASER BENDING LINE - ROLLERI B-LIGHT 01
This is a system utilized for bending without the use of Backgauge with the help of laser beam, and that allows the bending axis to be clearly visible.
Read more
RULER ON TOP BEAM
You can get precise results with Y1+Y2 axis synchronization with a tolerance of 0.01 provided by linear rulers.
ELECTRIC PANEL HEATING AND COOLING SYSTEM
An optional electric panel with heating and cooling system, manufactured in accordance with CE standards is provided.
TOOL STORAGE CABINET
This is a cabinet manufactured by Ermaksan to protect the upper and lower dies used in our machine from external impact, and to keep them clean.
ROLLERI TOOL CABINET
This is a cabinet manufactured by Rolleri to protect the upper and lower dies in our machine from external impact, and to keep them clean.
DELEM DA-66T
The 2D touchscreen display controller is your best assistant in the most difficult bending operations with its functional features.
Read more
DELEM DA-69T
DA-Touch series, 3D graphic display controller is always by your side to ensure the most precise bending operations with its powerful features.
Read more
CYBELEC VISITOUCH 19
Semi-compact control with 19” modern aerodynamic glass surface full touchscreen display and CNC board mounted on the back of the display.
Read more
CYBELEC VISITOUCH 19 MX
Features a 19” modern aerodynamic glass surface full touchscreen display. Has a compact structure with the CNC board mounted on the back of the display.
Read more
STANDARD CONTROLLER ARM
This is the standard equipment in which the CNC controller, which is required for the machine to work, is mounted and allows the controller to move to the front or back of the machine when required.
ERGONOMIC CONTROLLER ARM
It is a control panel arm type that allows you to easily move left and right, back and forth, in order to be more compatible with the operator working on the machine.
HEIGHT ADJUSTABLE CNC PENDANT ARM
This function is very practical when the machine is used by more than one operator and the height adjustment of the controller needs to be changed frequently.
Read more
L TYPE SLIDING FRONT SUPPORT ARM
Sliding front support arms with stopper, metric system scales and height adjustment feature allows more precise and easier bending operations.
Play
AP3-AP4 FRONT SUPPORT ARMS SYSTEM
This system prevents deformation of the bent sheet due to the flexing of the skirt share.
Read more
WIDE TYPE FRONT SLIDING ARM
They are optional foot type front arms used in machines with high sheet width and special bending.
U TYPE SLIDING FRONT SUPPORT ARM
It is the front arm body of all our machines (except Eco-Bend Expert), which is created using a light curtain and used for front security.
SIDE CAGE+SWITCH+AKASII
AKAS finger protection stops the movement of the upper beam when an object is detected.
Read more
SIDE CAGE+SWITCH+AKASII
AKAS finger protection stops the movement of the upper beam when an object is detected.
Read more
SIDE CAGE+SWITCH+DSP AP MCS
DSP MCS AP stops the movement of the upper beam when an object is detected. The beam continues to move if the object is removed.
SIDE CAGE+SWITCH+LASERSAFE IRIS
The system, which is also used as a front finger protection, stops the movement of the upper beam when an object is detected.
Read more
SIDE CAGE+SWITCH+LASERSAFE IRIS PLUS
This is a system that can measure the angle and automatically make angle correction to the CNC.
Read more
SIDE CAGE+SWITCH+LASERSAFE
The system, which is also used as front finger protection, stops the movement of the upper jaw when it detects any object.
Read more
CENTRAL LUBRICATING SYSTEM
Automatic lubrication of the parts that require lubrication for extended lifetime of the machine by central lubrication system, without the need for an operator.
Read more
CLOSED LOOP HYDRAULIC SYSTEM
It has a special closed loop hydraulic system. Maintenance requirement is minimal compared to hydraulic machines.
SERVO MOTOR BACKGAUGE
All motors used in the back rest are servo motors. Therefore, the sheet metal can be positioned with minimum precision.
REALISTIC 3D MODELLING (ER TOUCH)
The 3D feature of the controller allows the operator to distinguish the pieces to be processed from each other and provides ease of application.
LOW ENERGY CONSUMPTION (ECO-FRIENDLY)
The special hydraulic system has low energy consumption. It is also environmentally friendly with an average oil consumption of 34.5 litres.
QUIET OPERATION
With a sound level of 63 db, it is the quietest among sheet metal bending machines.
LOW OPERATING COST
Thanks to its low energy consumption, the operating cost is minimal. Thus, it provides advantages to the its users with high efficiency and low operating costs.
