ETP CNC Turret Punch Press
Maximum Efficiency and Profitability
ERMAKSAN has taken its place among the leading companies of the market with its punch product range, thanks to its years of experience and brand awareness that does not compromise on quality. ETP CNC Turret Punch combines hydraulic, electronic, and mechanical materials with world-renowned quality in a single machine and offers it to the industry.
ETP CNC Turret Punch Press, which allows various applications in sheets up to 6 mm thickness, has been designed to meet consumer needs for years with its steel construction and monoblock structure.
It offers the advantage of operating at high performance for many years with its hardened and stress-relieved O-type body structure.
- Strong rigid O-type body
- Ball table integrated with a brush
- 3 automatic clamping systems
- Hydraulic stroke system
- Mobile control panel and foot pedal
- Automatic tool kit lubrication system
BARCODE READER
Facilitates the operator's intensive and complex work processes and prevents errors.
Read more
VOITH TURBO H+L HYDRAULIC SYSTEM
VOITH TURBO is an integrated stroke unit specially optimized for punching, threading and forming applications.
Read more
CHAIN PROTECTION AROUND THE MACHINE
This is the chain protection system that ensures safety around the machine.
27 Stations
Different contours can be cut at desired angles with 3 automatic index stations in the turret. 11A+10B+1C+2D+(2B+1C AUTO INDEX)
Read more33 Stations
With 3 automatic index stations in the turret, different contours can be cut at desired angles, and optionally, 8A, 3B or 1C tools can be attached to these index stations, and many different tool combinations can be obtained. 15xA+12xB+2xC+1xD+(3xD AUTO INDEX)
Read more
GE FANUC Oi-PF
GE FANUC Oi-PF industrial control unit with graphic display has a very functional and practical interface.
Read more
AUTO NESTING
This is the function used to automatically duplicate and nesting the pieces on the CNC.
Read more
AIR BLOWING AND LUBRICATION SYSTEM
Airblow provides lubrication of tools and extends tool life.
Read more
WITH BRUSH AND BALL
Thanks to its special brushed design, this table ensures that the workpiece surface is manufactured without damage
Read more
HARDENED TOOL HOLDER
The hardened jacketed structure in the stations allows easy maintenance, replacement and retrofit of the stations at low cost.
RE-POSITION FUNCTION
With the RE-POSITION function, the machine can process sheet metal longer than the X axis without interruption.
NEXT GENERATION CONTROLLER
With Fanuc Oi-PF control unit, the system becomes user friendly, with more precise and faster positioning.
TOOL LUBRICATION
It offers the ability to lubricate automatically at every stroke with the lubrication system in the tools.
DISTORTION PREVENTION SYSTEM
The distortion prevention system used in machines with an axis length of 2500 mm provides more precise and long-lasting operation by preventing distortion and vibration on the ball screw.
RIGID CONSTRUCTION
With its hardened and stress relieved O-type body structure, it allows to operate with high performance for many years.
PRODUCT VIDEOS
Product Catalogue
Please click the link below to get detailed information about our products and to view our product catalogue digitally.
CataloguesOnline Catalog
Similar Products
Check out the other products in the category!
ETP-S
With its servo drive structure that does not use hydraulics, it allows various applications on sheet metals up to 6 mm thickness.
