THUNDERBIRD

2 kW – 6 kW power option
3x1.5m table size
Precitec / Raytools cutting head
Metalix / Lantek CAD/CAM
Beckhoff CNC Unit
IPG / MAX Laser Source
THUNDERBIRD

THUNDERBIRD

Economic in Every Aspect

The THUNDERBIRD fiber laser machine offers an easy entry to the world of fiber laser cutting with its compact structure that does not require costly equipment. The THUNDERBIRD for 2D laser cutting is the perfect entry-level machine that low investment costs and quality components make it a competitive offer. The machine available with an IPG /MAX 2, 3, 4 and 6kW laser source.

THUNDERBIRD enables high-quality cutting of thin sheets from steel and stainless steel to aluminum, copper and brass. While investment cost and operating costs are the key advantages of this machine, efficiency is one of the other advantages as well. With a table size of 3x1.5m, THUNDERBIRD Laser has two pallet design but without lift and hydraulic system. A longer Z-axis can be used instead.

It equipped with the Precitec / Raytools cutting head, which is the ideal solution for efficient and economical laser cutting in the medium power range. This controls the focus position fully automatically and delivers outstanding results when processing different material thicknesses. It offers permanently stable and precise operation and as well as quick and easy maintenance of the head is possible.

The electric cabinet embedded inside the machine. As well as positioning of the resonator is over the machine. The design, which does not affect the 3x1.5 m table size, is the same size as competing machines in its class. The compact structure of the machine, making it suitable for the workshops with a limited space. To maximize safety, it provides a safer work area with its light bodyguard in compliance with CE standards. This keeps employees safe when they are working around the machine.

Equipped with a Beckhoff controller that combines ease of use and stylish design, users of the THUNDERBIRD fiber laser machine can learn and control the entire manufacturing process quickly and easily. All the software designed and developed by Ermaksan engineers that offer flexible work arrangements into their unique business needs. The machine is easily programmed via the Metalix / Lantek CAD/CAM system, that decreases production time and material waste and increases productivity. Thanks to this compact structure customer will have lower transportation cost and faster installation. Roadways transport need only one normal trailer which means less transportation cost for the customer. The enclosure of the machine will not be dismantled for transport. This means easier and faster installation for the customer. Seaway transport needs 1x40' flatrack container and so seaworthy packaging of body in a steel case is necessary. You can avoid from it by dismantling the enclosure as well. THUNDERBIRD fiber laser system is a great choice for workshops need processing thinner sheets, without compromising standards and cutting quality, in despite of being an entry-level machine.

Smart Features
Controller
Software
Resonator
Cooling System
Cutting Head
Covering
Conveyor
Dry Air System
Proportional Valve System
Filtering System
Safety Equipment
Lubrication System
Automation System

COMPACT CONSTRUCTION

The electric cabinet embedded inside the machine and positioning of the resonator is over the machine. Thanks to this compact structure customer will have lower transportation cost and faster installation.

SHUTTLE TABLE

THUNDERBIRD Laser has two pallet design but without lift and hydraulic system. A longer Z-axis can be used instead.

MACHINE UPDATE

With the philosophy of continuous improvement, Ermaksan engineers offer the most up-to-date version allowing you to get the most out of your machine.

USER-FRIENDLY INTERFACE

Your work is now easier with the user-friendly interface designed by Ermaksan engineers. You can initiate automatic cutting processes with just a few steps, and monitor the active process before and during cutting with the NC Graphics feature.

LOW INVESTMENT COST

It offers an easy entry to the world of fiber laser cutting with its compact structure that does not require costly equipment. While investment cost and operating costs are the key advantages of this machine, efficiency is one of the other advantages as well.

SAVE TIME AND MONEY

It allows you to save both time and resources thanks to the shortening of energy consumption, and easy maintenance and repair.
