BSCRW
BSCRW – BALL SCREW ELECTRIC PRESS BRAKE
Green Power. Silent Operation. Exact Results.
Take your manufacturing into the future with the BSCRW Series. Designed with precision, sustainability, and efficiency in mind, this electric press brake features a servo-driven ball screw mechanism that delivers exceptional accuracy and rapid positioning—ensuring flawless, repeatable bends every time.
Available in a variety of bending capacities and sizes, the BSCRW enhances your production flexibility while minimizing energy consumption and operational costs. It’s the ideal solution for high-performance bending with maximum precision.
Set New Standards in Smart Manufacturing
The BSCRW isn’t just a press brake—it’s your gateway to smarter, cleaner, and more cost-effective production. Quiet, efficient, and environmentally friendly, it’s the perfect upgrade for future-ready operations.
IRIS PLUS LASER PROTRACTOR
Automatic angle measurement and automatic correction of bending angle
Read more Play
KEBA DIGITAL ANGLE GAUGE
With KEBA angle measuring systems, complex bends can be performed extremely easily and with maximum accuracy.
Read more
MITUTOYO UNIVERSAL ANGLE GAUGE
Can make your measurements more accurately with its sensitive adjustment.
Read more
BARCODE READER
Facilitates the operator's intensive and complex work processes and prevents errors.
Read more
LED BAR GUIDING SYSTEM
Shows the location of the bent pieces and bending stations with coloured LED bars.
Play
START-STOP
This is the optional system that stops the main motor when there is no upper beam movement in the machine within 2 minutes.
START-STOP + SOFT STARTER
This is the STAR - TRIANGLE motor speed change that we use as an option. Ensures safer and easier speed change for the motor.
4-AXIS BACKGAUGE
Backgauge with 4-axis (X, R, Z1, Z2) servo motor allows you to obtain precise bending of the backgauge with 0.05 mm positioning accuracy according to the desired geometry.
2-AXIS BACKGAUGE
Backgauge with 2-axis (X, R) servo motor allows you to obtain precise bending of the backgauge with 0.05 mm positioning accuracy according to the desired geometry.
5-AXIS BACKGAUGE
Backgauge with 5-axis (X, R, Z1, Z2, X5) servo motor allows you to obtain precise bending of the backgauge with 0.05 mm positioning accuracy according to the desired geometry.
Read more Play
ATF TYPE 6-AXIS BACKGAUGE SYSTEM
Ermaksan’s ATF Type Backgauge System is engineered for manufacturers who demand exceptional accuracy and efficiency in complex and multi-step bending operations.
Read more Play
SINGLE-AXIS BACKGAUGE
Backgauge single-axis (X) asynchronous motor and 0.05 mm positioning accuracy according to the desired geometry
REARGUARD+SWITCH
Ensure maximum operator safety with the integrated rear sliding guard and safety switch system.
Read more
MOTORIZED REAR SHUTTER DOOR
A motorized or manually operated rear safety door designed with durable aluminum slats.
Read more Play
DOUBLE FOOT PEDAL
A user-friendly dual foot pedal designed to offer precise and hands-free bending control.
Read more
MOTORISED CROWNING SYSTEM
The CNC-controlled motorised crowning system ensures consistent, even bend angles with automatic deflection compensation.
Read more Play
COBOT-INTEGRATED BENDING SYSTEMS
Ermaksan’s cobot-integrated press brakes make sheet bending processes safe, precise, and efficient, delivering a next-generation automation experience in manufacturing.
Read more Play
FULLY AUTOMATED ROBOTIC BENDING SYSTEMS
Ermaksan’s integrated robotic press brake systems fully automate sheet metal bending, delivering maximum efficiency, precision, and consistency on production lines.
Read more Play
RULER ON TOP BEAM
You can get precise results with Y1+Y2 axis synchronization with a tolerance of 0.01 provided by linear rulers.
STANDARD CONTROLLER ARM
The standard component that allows the CNC controller to be positioned at the front or rear of the machine when needed.
Read more
HEIGHT ADJUSTABLE CNC PENDANT ARM
Ideal for multi-operator use, this arm allows frequent height adjustments of the controller with ease.
Read more
AP3-AP4 FRONT SUPPORT ARMS SYSTEM
Advanced support solution for precise and safe sheet metal bending
Read more
WIDE TYPE FRONT SLIDING ARM
They are optional foot type front arms used in machines with high sheet width and special bending.
L TYPE SLIDING FRONT SUPPORT ARM
Sliding front support arms with stopper, metric system scales and height adjustment feature allows more precise and easier bending operations.
Play
U TYPE SLIDING FRONT SUPPORT ARM
It is the front arm body of all our machines (except Eco-Bend Expert), which is created using a light curtain and used for front security.
SIDE CAGE+SWITCH+LEUZE
If the brackets used as front light protection detect an object in the beam movement, they stop the movement of the beam; if the beam is removed, the beam keeps moving at the same speed. However; if the object remains in between, the beam keeps moving at a low (manual) speed.
SIDE CAGE+SWITCH+AKASII
AKAS finger protection stops the movement of the upper beam when an object is detected.
Read more
SIDE CAGE+SWITCH+AKASII
AKAS finger protection stops the movement of the upper beam when an object is detected.
Read more
SIDE CAGE+SWITCH+DSP AP MCS
DSP MCS AP stops the movement of the upper beam when an object is detected. The beam continues to move if the object is removed.
EASE OF INSTALLATION
The BSCRW press brake is designed for straightforward installation, reducing setup time and minimizing downtime.
OIL-FREE AND QUIET OPERATION
Fully electric and noise-reducing design ensures an environmentally friendly and comfortable workspace.
EXCEPTIONAL PRECISION
The servo-driven ball screw system guarantees accurate and consistent bends every time.
HIGH SPEED
Achieve up to 300 mm/s operation speed upon request, boosting productivity and efficiency.
LOW MAINTENANCE COSTS
With no hydraulic components and fewer moving parts, maintenance needs and costs are significantly reduced.
REPEATABLE ACCURACY
Consistent results across every cycle ensure uniformity in high-volume production
